In the modern industrial landscape, maintaining optimal airflow and temperature control is crucial for productivity and employee comfort. Our Industrial HVLS (High Volume Low Speed) Fans are engineered to provide efficient air circulation in large spaces, making them an essential addition to any industrial facility. With a focus on energy efficiency and durability, our fans are designed to meet the demanding needs of various industrial applications.
One of the standout features of our Industrial HVLS Fans is their energy efficiency. Unlike traditional high-speed fans, HVLS fans operate at low speeds while moving a large volume of air. This design not only reduces energy consumption but also lowers operational costs. By circulating air effectively, these fans can help maintain a comfortable temperature, reducing the need for additional cooling systems. This translates to significant savings on energy bills.
Our HVLS fans are specifically designed to cover expansive areas, making them perfect for warehouses, manufacturing plants, and distribution centers. With a single fan capable of moving air across a space of up to 20,000 square feet, you can ensure consistent airflow throughout your facility. This large coverage area helps eliminate hot spots and creates a more uniform temperature, enhancing the overall working environment.
Constructed from high-quality materials, our Industrial HVLS Fans are built to withstand the rigors of industrial use. The robust design ensures longevity and reliability, even in challenging environments. Each fan undergoes rigorous testing to ensure it meets our high standards for performance and durability. This commitment to quality means you can trust our fans to deliver consistent airflow for years to come.
| Model | Size (M) | Motor Power (KW) | Rotation Range (RPM) | Max Air Volume (M³/Min) | Coverage Area (M²) | Voltage (V) | Current (A) | Weight (KG) | Noise (dB) | Consumption (KW·H) |
|---|---|---|---|---|---|---|---|---|---|---|
| Aloemax7.3 | 7.3 | 1.5 | 10-58 | 13850 | 1100 | 380/220 | 3.4 | 120 | 40 | 1.5 |
| Aloemax6.1 | 6.1 | 0.8 | 10-60 | 12000 | 1000 | 380/220 | 2.9 | 102 | 40 | 0.8 |
| Aloemax5.5 | 5.5 | 0.8 | 10-65 | 11000 | 850 | 380/220 | 2.8 | 85 | 40 | 0.75 |
| Aloemax4.9 | 4.9 | 0.8 | 10-70 | 10000 | 700 | 380/220 | 2.7 | 80 | 40 | 0.75 |
| Aloemax4.2 | 4.2 | 0.4 | 10-75 | 9000 | 550 | 380/220 | 2.0 | 68 | 40 | 0.4 |
| Aloemax3.8 | 3.8 | 0.4 | 10-85 | 8000 | 450 | 380/220 | 2.0 | 65 | 40 | 0.4 |
| Aloemax3.3 | 3.3 | 0.4 | 10-95 | 7000 | 400 | 380/220 | 2.0 | 60 | 40 | 0.35 |
| Aloemax2.5 | 2.5 | 0.3 | 10-100 | 5000 | 300 | 220 | 2.0 | 55 | 40 | 0.3 |
| Model | Size (M) | Motor Power (KW) | Rotation Range (RPM) | Max Air Volume (M³/Min) | Coverage Area (M²) | Rated Voltage/Current | Weight (KG) | Noise (dB) | Consumption (KW·H) |
|---|---|---|---|---|---|---|---|---|---|
| Aloeplus7.3 | 7.3 | 1.5 | 10-58 | 13850 | 1100 | 380V/3.3A | 127 | 42 | 1.5 |
| Aloeplus6.1 | 6.1 | 1.5 | 10-60 | 12500 | 1000 | 380V/2.5A | 112 | 42 | 1.5 |
| Model | Size (M) | Motor Power (KW) | Rotation Range (RPM) | Max Air Volume (M³/Min) | Coverage Area (M²) | Voltage (V) | Current (A) | Weight (KG) | Noise (dB) | Consumption (KW·H) |
|---|---|---|---|---|---|---|---|---|---|---|
| Aloepro7.3 | 7.3 | 1.5 | 10-60 | 13650 | 1000 | 380/220 | 3.4 | 113 | 40 | 1.45 |
| Aloepro6.1 | 6.1 | 0.8 | 10-65 | 11500 | 900 | 380/220 | 2.9 | 100 | 40 | 0.75 |
| Aloepro5.5 | 5.5 | 0.8 | 10-70 | 10500 | 800 | 380/220 | 2.8 | 82 | 40 | 0.7 |
| Aloepro4.9 | 4.9 | 0.8 | 10-80 | 9800 | 700 | 380/220 | 2.7 | 80 | 40 | 0.7 |
| Aloepro4.2 | 4.2 | 0.4 | 10-90 | 8900 | 550 | 380/220 | 2.0 | 69 | 40 | 0.4 |
| Aloepro3.8 | 3.8 | 0.4 | 10-95 | 7900 | 450 | 380/220 | 2.0 | 67 | 40 | 0.4 |
| Aloepro3.3 | 3.3 | 0.4 | 10-100 | 6950 | 400 | 380/220 | 2.0 | 64 | 40 | 0.35 |
| Aloepro2.5 | 2.5 | 0.3 | 10-120 | 4950 | 300 | 220 | 2.0 | 53 | 40 | 0.3 |
